Chain Link Gate Hinges - Post Hinges, Frame Hinges, and More

Our chain link gate hinges collection covers every hinge style needed for swing gate installation on chain link fences. Choose from post hinges (male pin, mounts to the post), frame hinges (female receiver, mounts to the gate frame), 180-degree commercial hinges (allow the gate to swing fully open against the fence), flat-back wall mount hinges, and wood post hinges (for attaching chain link gates to wood fence posts). All hinges are manufactured from galvanized steel for corrosion resistance. Use 2 hinges per standard single swing gate. Always measure your gate post outside diameter and gate frame outside diameter before ordering.

Frequently Asked Questions

How many hinges do I need for a chain link gate?

Most standard single-swing chain link gates require 2 hinges. Heavy gates over 6 feet tall or gates on high-traffic commercial entrances may benefit from 3 hinges for added support and smooth operation.

What is the difference between a post hinge and a frame hinge?

A post hinge (male pin) mounts to the fence post. A frame hinge (female receiver) mounts to the gate frame. They work together as a pair - the male pin drops into the female receiver to create the swing pivot.

How do I measure for chain link gate hinges?

Measure the outside diameter of both your gate post and your gate frame. Post hinges are sized by post OD; frame hinges are sized by frame OD. Common sizes are 1-5/8 and 1-7/8 inch for frames and 2-3/8 to 8-5/8 inch for posts.

What is a 180-degree gate hinge?

A 180-degree gate hinge allows the gate to swing a full 180 degrees and lie flat against the fence line when fully open. This is ideal for driveways and commercial entrances where full-width clearance is needed.

Can I use chain link gate hinges on a wood fence?

Not directly. Chain link gate hinges are designed to clamp onto round tubular fence posts. For wood fence posts, use wood post hinges that mount with lag screws or J-bolts.

What causes chain link gate hinges to sag over time?

Sagging is usually caused by hinges that are undersized for the gate weight, worn hinge pins, or loose mounting hardware. Retighten all hardware first; if the hinge pin is visibly worn, replace the hinge pair.

Are chain link gate hinges adjustable?

Most standard chain link gate hinges are not height-adjustable once installed. For adjustable height, look for hinges with slotted mounting holes that allow vertical repositioning after installation.

What is the difference between residential and commercial gate hinges?

Commercial-duty gate hinges are manufactured from heavier gauge steel, have larger bearing surfaces, and are rated for more cycles and heavier gates than residential hinges. Use commercial hinges for high-traffic or heavy-gate applications.

How do I install chain link gate hinges?

Mount the post hinge to the fence post using the included U-bolts, then mount the frame hinge to the gate frame. Drop the gate onto the post hinge pins to complete the assembly. No welding is required.

What is the hinge pin diameter for standard chain link gate hinges?

Most standard residential and commercial chain link gate hinges use a 5/8 inch hinge pin. Always confirm pin diameter when mixing components from different sources to ensure compatibility.
